Vibration Calibrator Vibrometer Vibration Meter Calibrator Self-Contained Handheld Shaker Designed for Quick and Easy Checking of Accelerometers Vibration Monitoring Systems Recording Systems

Product description

Introduction

The Vibration Calibrator is a small, self-contained handheld shaker designed for fast and straightforward checking of accelerometers, vibration monitoring methods and recording methods. Offering a recognized and managed RMS vibration for verification of accelerometers weighing as much as 150g.

Characteristic:

Operates at 159.2 Hz.10 mm/s RMS velocity output.Drives vibration sensors as much as 150g.CE compliant.

Product introduction

It’s used for calibrating varied vibration meters. This vibration meter calibrator is a compact, impartial handheld vibration sieve, specifically designed for the fast and easy detection of accelerometers, vibration monitoring methods and recording methods.

Product parameters

Working Frequency:159.2Hz±0.5percentAcceleration Output:14.14m/s²(Peak)±3percentVelocity Outout:10mm/s(RMS)±3percentDisplacement Output:28um(Peak-Peak)±4percentTransverse Output:<5percentDistortion:<3percentMaximum Losd:150 gRamp-Up Time:<3 Seconds

Product Specs

Working Circumstances

Temp: -10°C~40°CHumidity: <85percentRH

Battery Provide:4×1.5V AA (UM-3) battery(Batteries aren’t included throughout the cargo)Measurement (Diamter x Top):56 mm x 200 mmWeight (with batteries):960g

Software

The Vibration Calibrator is a small, self-contained handheld shaker designed for fast and straightforward checking of accelerometers, vibration monitoring methods and recording methods. Offering a recognized and managed RMS vibration for verification of accelerometers weighing as much as 150g.
Working Frequency:159.2Hz±0.5%
Acceleration Output:14.14m/s²(Peak)±3%
Velocity Outout:10mm/s(RMS)±3%
Displacement Output:28um(Peak-Peak)±4%
